More Product Photographs

Product Data

Straight Wall Tooled Bowl

Bowl Sizes Available - 6",9",12",15",18",24" and 36"
(Please consult factory for bowls exceeding 24")

Vibratory Drivers

Drivers - 6",9",12",15",18",24" and 30"
(Please consult factory for bowls exceeding 24")

Linear Vibratory Tracks

Individual tracks up to 3 ft. in length.

Gravity Tracks

As required, up to 180 deg. twist.

Hoppers

Hoppers capacity - 1/4 cu. ft. to 25 cu. ft.

Bulk Material Feeders

Bulk matreial feeding systems - Pan, Tube, or V-shaped trough configurations available in mild steel or stainless steel with capacities up to 20 tons per hour. Custom applications available.

Sound Enclosures

Standard sizes to accommodate up to 36" feeder bowls.

Machine Frame/Base

Designed and fabricated to meet your system requirements.

Feeder System Options

Parts Sensors - Counters, Detectors, Control (on/off)

Bagging and/or Packaging Systems

Feed Rate Controllers For Bowls, Hoppers, Tracks

Bowl Coatings - Eletro-Polish, ESD Protection, Porcelain, PVC, Teflon

Heated Tracks

System Specifications

Power Requirements

110 VAC, 50 or 60 Hz

Standard Feeder Bowl Dimentions

Vibratory Feeder Bowl

	6"	9"	12"	15"	18"	24"	36"
A	3"	4.5"	6"	7.5"	9"	12"	18
B	5"	7.5"	10"	12.5"	15"	*	*
C	10"	15"	20"	25"	30"	*	*
D	4.75"	5.25"	6.125"	8.375"	10"	*	*
E	7"	9.75"	11.625"	15.375"	19"	*	*









* Dimensions will vary with size and configuration of part to be fed.

Ordering Information

For a quotation on delivery and pricing the following information is required.

Sample Parts (Including Prints If Available)

Bowl Size Requirements

Orientation Requirements

Feed Rate Requirements

Option Requirements

Delivery Requirements
